Basic Info.
Model NO.
MJL803C10R6-E
Certification
Craa
Application
Cooler
Principle
Refrigeration Heat Exchanger
Style
Ceiling Type
Material
Stainless Steel
Voltage
380V/3p/50Hz
Fan Motor Dia.
800mm
Fan Qty
3PCS
Cooling Capacity
124.4kw
Color
White
Heat Area
357.40m2
Air Flow Rate
63500m3/H
Air Flow
67meters
Noise
64dB
Weight
795kg
Transport Package
Wooden Casing
Specification
2620*798*890mm
Trademark
Zhexue
Origin
China
HS Code
8418991000
Production Capacity
20 Sets/Day
Packaging & Delivery
Package Size
262.00cm * 80.00cm * 90.00cm
Package Gross Weight
795.000kg
Product Description
ZHEXUE brand evaporator is suitable for any kinds of cold storage for the food ,vegetables,food processing workshop and logistics center. The compact design of our evaporators save much space for our clients, we also choose the external fan motor with lower noise to build a comfortable environment.
ZHEXUE evaporators' cooling capacity range is from 1.0kw to 210kw, they are used for Freon such as R134A,R22,R404A,R507C and R407C.
Products Feature
- Designed by the advanced European technology , make the products more efficiency.
- The external casing is s/s or etgalvanized steel sheet with electrostatic spraying technology, comply with hygiene standards.
- The inner casing is anti corrosive aluminium sheet and the floating coil design can prevent pipe broke.
- Using 15.88mm copper pipe and 12.7mm inner thread copper pipe, special length between pipes and advanced technology of heat exchange surface make our evaporator more efficiency.
- Fins stamping equipment adopts scientific mold , using 15.88mm pipes and 12.7mm inner thread pipes, it reduce the wind resistance.
- Equipped with the extended wind guide,it can improve the motors efficiency and raise the air flow (motors more than 500mm)
- We have windshield at the bottom of the fan coils, it can prevent the air through the water tray,then more wind will through out the fan coils to improve the heat exchange efficiency.
- All evaporators are equipped with the international brand external fan motors.
- Optimized pipe rows and lines design and different liquid distributor can improve the heat exchange efficiency based on the different condition.
- All evaporators are equipped with the connection of pressure gauge.
- All evaporators are equipped with best brand s/s ele. Heaters to defrost quickly.
- The compact design saves much Freon
- Middle and big size evaporator are equipped with the installation frame, it is easy to transport and install.
Model Description
MJ L 50 3 C 06 R6 -F
MJ: Brand : MAJORROLE
L: L: Large industrial type B: Commercial type H: High efficiency type
50: Fan dia: 50 means 500mm fan motor
3: Fan qty
C : Module: C: square T:triangle D:Double air out
06: fin space
R6:pipe rows
-F: S: s/s casing L: aluminum casing SS:s/s casing with s/s fan motor
B : air out from fin side E: electrical defrost H: hot gas defrost
W: water defrost F: customized
| Φ800mm-10P R404A | |||||
| C10=10mm Fin space | |||||
| Model | MJL802C10R6-E | MJL802C10R8-E | MJL803C10R6-E | MJL803C10R8-E | |
| Cooling capacity (kw) | SC1(△t=10K) | 82.40 | 101.90 | 124.40 | 153.80 |
| SC2(△t=8K) | 55.90 | 69.20 | 85.10 | 105.30 | |
| SC3(△t=7K) | 42.30 | 51.60 | 64.70 | 79.30 | |
| SC4(△t=6K) | 34.80 | 42.60 | 53.60 | 65.60 | |
| SC5(△t=6K) | 34.20 | 42.20 | 52.10 | 64.40 | |
| heat exchange area(m2)) | 237.40 | 316.60 | 357.40 | 476.20 | |
| tube volume (dm³) | 80.90 | 107.90 | 121.80 | 160.90 | |
| air flow rate (m³/h) | 42300 | 40900 | 63500 | 61400 | |
| total fan power (W) | 3800 | 3800 | 5400 | 5400 | |
| total fan current (A) | 7.80 | 7.80 | 11.70 | 11.70 | |
| air flow (m) | 64 | 63 | 67 | 66 | |
| defrost power (W) | 32400 | 43200 | 46800 | 62400 | |
| pipe dia. in/out (Φmm) | 2*35/2*64 | 2*35/2*64 | 2*35/2*64 | 2*42/2*76 | |
| noise(db) | 62 | 62 | 64 | 64 | |
| weight(kg) | 530 | 560 | 795 | 845 | |
