Basic Info.
Application
Heat Transfer
Principle
Mixing Heat Exchanger
Style
Steel Type
Material
Stainless Steel
Plate Material
Carbon Steel, Stainless Steel
Type
Tube Fin Type
Design Temp
as Per C
Fin Type
Flat, Corrugated, Louvered
Tube Material
Copper, Stainless Steel, Aluminium, Titaniu
Transport Package
Polywood Box
Specification
ISO9001: 2008, SGS
Trademark
Tranp
Origin
Guangzhou, China
HS Code
8419909000
Production Capacity
900.0 Unit/Units Per Month
Packaging & Delivery
Package Size
100.00cm * 100.00cm * 100.00cm
Package Gross Weight
100.000kg
Product Description
The air radiator is the main device of the heat exchangers using a cold medium and a heat medium for air cooling or heating. It can heat air if fed with high-temperature water, steam or heat transfer oil, or cool air if fed with saltwater, so it is extensively used in the warm-air heating, air-conditioning, cooling, condensing, dehumidifying and drying in fields such as light industry, architecture, chemical industry, machinery, textile, printing and dyeing, electronics, food, pharmaceutical industry, metallurgy, wood, plastics, rubber, etc.
Function
Air heater can be used for the air heating purpose of both steam systems and hot water systems. It is mainly used for the air heating of warm-air heating system, air-conditioning systems, and drying devices. As the main part of air heating devices, it is widely used in the heating and ventilation systems of the large buildings of present industrial and mining enterprises.
The heat medium of the air radiator may be steam, hot water or heat transfer oil. The operating pressure of steam is 0.2 MPa to 1.6MPa; the temperatures of hot water and heat transfer oil are about 70ºC to 150ºC and 160ºC to 300ºC respectively.
finned tube
Selection principles, steel standards, thermal treatment states and permissible stress values of the materials of the pressure parts should be subject to requirements of the GB 150. The pressure parts used in inflammable, fatal or toxic operating environments should be made of cast iron.
The common parent tube materials include carbon steel Q235B, 20#, 304, 316, copper tube, etc.
The common fin materials include carbon steel, 304, 316, aluminum, etc.
About Warranty:
We promise 1 year guarantee, all reasonable relevant cost will be undertaken by us in the first year if our heat exchanger fails to work due to quality problem, only the free repairing operation guide is available in the rest of the years via E-mail /Fax/Phone
