Basic Info.
Model NO.
CBM26
Principle
Recuperative Heat Exchanger
Style
Plate
Material
Stainless Steel
Product Type
Heat Exchanger
Max Pressure
3/4.5 MPa
Test Pressure
4.5/6.7 MPa
Volum Pr Channel
0.25 L
Exchange Area (M2)
0.095(N-2)
Max Temperature
225c
Structure Material
Metal Material
Type
Stainless Steel Heating Equipment
Heat Transfer Surface
Plate Heat Exchanger
Transport Package
Standard Plywood Box
Specification
ISO9001, CE, UL, WRAS, ROHS and etc.
Trademark
Baode
Origin
China
HS Code
8419500090
Production Capacity
1000 PCS/Month
Product Description
CBM26 CB76 oil cooler in marine flange connection
Working Principle
Brazing the stainless steel plates together eliminates the need for sealing gaskets and thick frame plates. As well as holding
The plates together at the contact points, the brazing material seals the package. Baode's brazed heat exchangers are brazed
At all contact points, ensuring optimal heat transfer efficiency and pressure resistance. The plates are designed to achieve
Longest possible lifetimes. Since virtually all material is used for heat transfer, the Brazed Plate Heat Exchanger is very compact
In size and has a low weight and a low hold-up volume. The BPHE (Brazed Plate Heat Exchanger ) consists of thin corrugated
Stainless steel plates which are vacuum brazed together using copper as the brazing material. Copper brazed units can be used for numerous of applications. For food applications and applications involving aggressive fluids, Nickel brazed units are requested.
Refrigeration Systems:
Evaporator,
Condenser,
Economizers and Desuperheaters
Air dryer
Heat pump
Absorption chiller
HVAC
Radiant Floor,
Snow Melt,
Boiler
Solar water heat exchanger
District heating
Other Industrial applications such as:
Heat Recovery
Oil Cooler: Hydraulic oil cooling, engine oil cooling, and fuel oil heating.
Steam Heating.
Flat plate heat exchanger
Beer wort cooler
Milk pasteurization
Wind turbine oil cooler
Marine oil cooler
Short delivery time.
High quality
Reasonable price
Customer made
Know-how design and customer support
Working Principle
Brazing the stainless steel plates together eliminates the need for sealing gaskets and thick frame plates. As well as holding
The plates together at the contact points, the brazing material seals the package. Baode's brazed heat exchangers are brazed
At all contact points, ensuring optimal heat transfer efficiency and pressure resistance. The plates are designed to achieve
Longest possible lifetimes. Since virtually all material is used for heat transfer, the Brazed Plate Heat Exchanger is very compact
In size and has a low weight and a low hold-up volume. The BPHE (Brazed Plate Heat Exchanger ) consists of thin corrugated
Stainless steel plates which are vacuum brazed together using copper as the brazing material. Copper brazed units can be used for numerous of applications. For food applications and applications involving aggressive fluids, Nickel brazed units are requested.
Refrigeration Systems:
Evaporator,
Condenser,
Economizers and Desuperheaters
Air dryer
Heat pump
Absorption chiller
HVAC
Radiant Floor,
Snow Melt,
Boiler
Solar water heat exchanger
District heating
Other Industrial applications such as:
Heat Recovery
Oil Cooler: Hydraulic oil cooling, engine oil cooling, and fuel oil heating.
Steam Heating.
Flat plate heat exchanger
Beer wort cooler
Milk pasteurization
Wind turbine oil cooler
Marine oil cooler
Short delivery time.
High quality
Reasonable price
Customer made
Know-how design and customer support
| Model | BL95 |
| Max pressure (Mpa) | 3/4.5 |
| Test pressure(Mpa) | 4.5/6.7 |
| Volum pr channel(L) | 0.25 |
| Exchange area (M2) | 0.095(n-2) |
| Max Temperature | 225C |
| Width(mm) | 191 |
| Height(mm) | 616 |
| Horizon hole(mm) | 92 |
| vertical hole(mm) | 519 |
| Length(mm) | 11+2.35N |
| Weight(kg) | 7.0+0.36N |
